MeasuringRange:-0.1~0~0.02...100MPa

OperatingTemperature:-20~85

PowerSupply:24VDC

MeasuringRange:-0.1~0~0.02...100MPa

Shell Material:AluminiumAlloy

OperatingTemperature:-20~85

Measurement Range	0~35KPa．．．~100MPa
Proof pressure	≤1.5X rated pressure or 110MPa which ever is less
Pressure type	Gauge, absolute ,sealed gauge
Accuracy	±0.25%（Typical） ±0.5%（Max.）
Long term stability	±0.2%F.S/year
Temperature Error- Zero	-20℃~80℃
Temperature Error -Span	-40℃~120℃
OperatingTemperatureRange	15～30VDC
Storage TemperatureRange	4～20mA 0～10/20mA 0/1～5VDC
Power supply	M20×1.5 or customize
Output signal	Cast aluminium alloy(E+H)
Pressure port	316L
O-ring	Fluororubber
Cable	Polyethylene
Insulation resistance	100MΩ 100VDC
Protection	IP65

Note: The wire connection is non-polarity 2-wire connection. The excitation and output can be connected with any side of the wire connecting terminal.

Measurement Range	0~35KPa．．．~100MPa
Proof pressure	≤1.5X rated pressure or 110MPa which ever is less
Pressure type	Gauge, absolute ,sealed gauge
Accuracy	±0.25%（Typical） ±0.5%（Max.）
Long term stability	±0.2%F.S/year
Temperature Error- Zero	-20℃~80℃
Temperature Error -Span	-40℃~120℃
OperatingTemperatureRange	15～30VDC
Storage TemperatureRange	4～20mA 0～10/20mA 0/1～5VDC
Power supply	M20×1.5 or customize
Output signal	Cast aluminium alloy(E+H)
Pressure port	316L
O-ring	Fluororubber
Cable	Polyethylene
Insulation resistance	100MΩ 100VDC
Protection	IP65

Note: The wire connection is non-polarity 2-wire connection. The excitation and output can be connected with any side of the wire connecting terminal.

No matter which terminal side the excitation or output connects with, the effect is the same.

欧美日本国产老熟女视频,亚洲欧美日韩国产专区,婷婷丁香五啪啪五月综合,精品第一国产综合精品AⅤ

PRM301 Intrinsically Safe Pressure
